Statfax 4300 Microplate Reader
Ultra‑fast absorbance reading for high‑throughput ELISA workflows.
- PHOTOMETRIC
- Filter options from 405nm to 700nm
- ELECTRONIC:
- SOFTWARE
- Enclosure:
- Weighs 10lbs. (4.5kg)
Overview
The Statfax 4300 delivers fast, reliable absorbance measurements for ELISA and other colorimetric assays, supporting standard 96‑well plates or strip trays.
Its remote halogen lamp with lamp‑saver, six interference filters, and USB‑enabled eZ80 processor provide stability, flexibility and seamless integration into existing laboratory workflows, including real‑time data logging.
Key Features
- Optical range –0.20 to 4.0 A with ±1% photometric accuracy
- Six interchangeable IAD hard‑coat interference filters (405‑630 nm, 10 nm half‑bandpass)
- Remote halogen lamp with lamp‑saver extends source life
- Rapid 96‑well reading in ~8 seconds via stepper‑motor transport
- USB connection and eZ80 microprocessor for seamless data transfer
- Auto‑sensing 115 V/230 V power, compact ABS housing (10 lb)
- Flame‑retardant ABS enclosure ensures safety
Applications
- Clinical diagnostics ELISA testing
- Research immunoassays in universities
- Serology screening in blood banks
- Pharmaceutical compound profiling
- Environmental toxin detection
- Immunology studies in private clinics
Why Choose This Product
Designed for high‑throughput laboratories, the Statfax 4300 combines precise photometry, flexible filter selection, and intuitive USB interfacing in a lightweight, space‑saving enclosure. Its rapid 8‑second plate read and reliable lamp‑saver technology maximize productivity while maintaining data integrity.
Mon–Fri 8am–6pm | Sat 9am–3pm
Technical Specifications
| Optical Measurement Range | -0.20 to 4.0 Absorbance units (A) |
| Photometric Accuracy | +/-1 |
| Stability | Drift of no more than 0.005A in 8 |
| Light Source | Remote halogen lamp source with lamp saver feature |
| Wavelengths | Standard: 405, 450, 492, 545, 600, and 630nm |
| 6-filter | 405, 450, 492, 545, 600, and 630nm |
| Filter type | IAD hardcoat interference, 10nm half bandpass |
| Vessel | Standard 96-well micro titer plates, or strip trays. |
| Power Requirements | 115V or 230V AC, 50-60Hz (auto-sensing) |
| PC Connection | USB Port |
| Microprocessor | eZ80 |
| Speed | Reads absorbance of 96 wells in about 8 seconds. |
| Plate Transport | Stepper motor |
| Certifications | Pending |
| Calculation Modes | Single point calibration, point-to-point curve fit, |
| Flame | retardant ABS plastic cover and base |
| Dimensions | Approx. 7.5 x 13.0 x 16.5 (19 x 20.3 x 42cm) |
Specifications are subject to change without notice. Contact Waxtron Medicals for the most current datasheet.
Clinical Use Cases & Applications
Hospitals
Ideal for this healthcare setting.
Diagnostic Laboratories
Ideal for this healthcare setting.
Universities
Ideal for this healthcare setting.
Research Institutes
Ideal for this healthcare setting.
Blood Banks
Screening and compatibility testing.
Private Clinics
Ideal for this healthcare setting.
Clinical Applications
Shipping & Delivery Information
| Zone | States | Timeline | Base Cost |
|---|---|---|---|
| Zone 1 | FCT Abuja | 1–2 days | ₦2,000 |
| Zone 2 | Lagos, Ogun, Oyo, Osun, Ondo, Ekiti | 2–4 days | ₦5,000 |
| Zone 3 | Rivers, Delta, Edo, Cross River, Akwa Ibom, Bayelsa | 3–5 days | ₦6,000 |
| Zone 4 | Kano, Kaduna, Katsina, Sokoto, Kebbi | 2–4 days | ₦4,500 |
| Zone 5 | Enugu, Imo, Anambra, Abia, Ebonyi | 3–5 days | ₦5,500 |
| Zone 6 | All other states | 4–7 days | ₦7,000 |
* Weight-based surcharges apply for equipment above 50kg
Our Delivery Promise
Customer Reviews
After putting it through regular use, it has been a practical investment for our facility. It has worked well alongside the other systems in our laboratory.
One of the better aspects of this purchase is that we are pleased with the general performance and reliability. We mainly use it for sample processing.
For the type of work we handle, it has performed well enough for us to recommend it. That consistency has been important for our daily operations.
Having used several laboratory products before, it has performed consistently during normal daily use. The operators have been able to incorporate it into their normal routine. Most of our usage has been around sample processing.
One practical benefit we have noticed is that our staff have adapted to it well and we have been satisfied with the results.
After several months of regular use, it has performed well for our needs, particularly during routine work. We have found it dependable enough for continued routine use. Our team has found it useful for routine laboratory analysis.
Our procurement team chose this model because we have found the system reliable for our regular workload. It has worked well alongside the other systems in our laboratory.
We needed something suitable for daily laboratory work, and it has integrated well with the way our laboratory already operates. The operators have been able to incorporate it into their normal routine.
For a busy diagnostic centre like ours, it has given us the consistency we were looking for.
Our laboratory needed a dependable solution and we have been satisfied with its performance during routine work. It has provided the level of consistency we needed.
I particularly like the fact that we have been satisfied with its performance during routine work. So far, it has been a dependable part of our routine work.
Having this available has made it easier to the overall experience has been positive, especially for routine laboratory work. The team was able to get used to the workflow fairly quickly. Most of our usage has been around routine laboratory analysis.
It has been a good fit for our existing workflow because it has fitted comfortably into our existing workflow. The staff feedback has generally been positive. Most of our usage has been around diagnostic testing.
We selected this after considering our daily workload, and the system has performed well overall and has become useful to our staff. The day-to-day operation has been straightforward for our team.
I would say the strongest point for us has been the unit has been performing steadily since installation.
After putting it into service, our team found that it has given us the consistency we were looking for. We would consider purchasing the same model again if the need arises.
You need to be logged in to write a review.
Login to ReviewFrequently Asked Questions
Does this equipment work with Nigerian power supply?
Yes. This equipment features a wide AC input range (100–240V, 50/60Hz), making it fully compatible with Nigerian power supply. We recommend pairing it with a quality voltage stabilizer (1.5–2 KVA) for optimal performance. Our engineers will advise on the right stabilizer during installation.
Is installation really free?
Yes, absolutely. Every equipment purchase from Waxtron Medicals includes free delivery to your facility, installation, commissioning, and operator training — all at no extra cost. Our biomedical engineer visits your site and stays until the equipment is fully operational and your staff are trained.
What warranty is included?
All equipment carries a 12-month comprehensive warranty from the date of installation. This covers manufacturing defects and component failures under normal use conditions. Warranty service is performed at your facility by Waxtron's biomedical engineers — you do not need to ship the equipment anywhere.
Can I pay in instalments?
Yes. We offer 0% instalment plans for 3–6 months (minimum 30% deposit). For purchases above ₦5 million, we offer bank-backed financing for up to 24 months through our banking partners. Monthly payments for this product start from ₦N/A. Visit our Financing page or speak to our team for details.
Do you supply the reagents for this equipment?
Yes. We supply all compatible reagents, calibrators and controls. We recommend setting up a reagent supply agreement with Waxtron for scheduled deliveries and fixed pricing — ensuring you never experience stock-outs that disrupt lab operations.
How long does delivery take to my state?
FCT Abuja: 1–2 business days. Lagos/PH: 2–4 days. Northern states: 2–4 days. South East/South South: 3–5 days. Remote northern states: up to 7 days. Use the shipping calculator on this page for a specific estimate for your state.
What happens if the equipment breaks down?
Call or WhatsApp us at +234 706 756 4166 immediately. Many issues can be resolved remotely. For hardware faults, our engineer will visit within 24–72 hours (Abuja) or 2–5 business days (other states). We carry common spare parts and maintain OEM parts stock for all equipment we sell.
Is Waxtron Medicals NAFDAC registered?
Yes. Waxtron Medicals Ltd is a NAFDAC-registered medical device supplier. We can provide full NAFDAC and regulatory documentation for your facility records, NHIA accreditation applications, or government procurement submissions.
