Chemwell T Fully Automated Chemistry Analyzer
Automated chemistry analysis delivering high throughput and precise reagent handling
- General Reagent and Sample Handling
- Precision for volumes
Overview
The Chemwell T is a fully automated chemistry analyzer designed for high-throughput clinical and research environments. It delivers up to 32 tests within a three-hour assay cycle, including calibrators and controls, ensuring consistent workflow efficiency.
Precision engineering in the syringe pump, 316L stainless-steel probe, and adjustable mixing system guarantees exact reagent volumes from 2 µl to 450 µl. With a 500 µl pump capacity and 0.5 µl increment settings, the system meets demanding sample-handling requirements while maintaining reliable performance.
Key Features
- Throughput of 32 tests per 3‑hour assay, including calibrators and controls
- Syringe pump with 500 µl capacity and 0.5 µl incremental dispensing (2‑450 µl range)
- 316L stainless‑steel probe for superior reagent compatibility and level sensing
- Adjustable probe oscillation for precise mixing speed and time
- Integrated functions: dilution, pre‑dilution, and automated sample/reagent dispensing
- Minimal reagent waste: total initial volume 255 µl, with 65 µl per‑sample allocation for each reagent
- User‑friendly interface with customizable protocols
Applications
- Hospital clinical chemistry laboratories
- Diagnostic and reference laboratories
- University and research institute laboratories
- Blood bank testing facilities
- Government health agency laboratories
- Private and specialty clinics
- Veterinary diagnostic labs
Why Choose This Product
Engineered for reliability and precision, the Chemwell T combines high throughput with exact reagent handling, reducing waste and turnaround time. Its versatile automation and intuitive software adapt to varied testing volumes, making it suitable for both large hospitals and focused research settings.
Mon–Fri 8am–6pm | Sat 9am–3pm
Technical Specifications
| Typical throughput | 32 test per 3 hour assay procedure including calibrators and controls |
| Total reagent volume Initial | 255 µl |
| per sample | R1, R2, R3: 65µl each |
| Final reagent | 60µl |
| Extraction | 300µl |
| Reading | 200µl |
| Functions | Dilution, pre-dilution, dispensing samples and reagents |
| Syringe Pump | Capacity 500µl, range 2µl – 450µl. Settings in increments of 0.5µl |
| Probe | 316L stainless steel for maximum reagent compatibility, level sensing |
| Mixing | Probe oscillation, time and speed adjustable |
| Precision for volumes <5µl | <2% CV |
| Max. number of reactions | 40 |
| samples | can be increased with custom design |
| Instrument bottles | 250mL priming bottle |
| Thermal Control | Reagent Cooling is standard; cools 8° to 12°C below ambient through Peltier thermoelectric module |
| Optical design | User-selected monochromatic or dichromatic results 8 position filter wheel: 340, 405, 505, 545, 570, 580, 630, + one optional |
| Interference filters | Long life, hard coat, ion assisted deposition, 10nm typical half band pass |
| Linear range | 0.0 to 3.0A |
| Photometer accuracy | ±(1% of the reading + 0.005A) from 0 to 1.0A |
| Format | USB with internet upgrades |
| Supports | Windows®XP, Vista, or 7(Computer not supplied) |
| Recommended System | Windows®XP, Vista, or 7. 512MB SDRAM, CD drive, USB port |
| Calculation System | Absorbance, single standard, factor, fixed time kinetics, kinetics by standard of factor, multi-calibrator point-to-point, linear regressions, cubic spline, and percent absorbance |
| Self monitoring modes | Lamp, filters, reagent levels, mechanical function, and more |
| QC options | Store control data, print Levey-Jenings or QC range plots |
Specifications are subject to change without notice. Contact Waxtron Medicals for the most current datasheet.
